This page configures GitHub OAuth sign-in for DevPortal 3.x and the GitHub organization sync that imports users and teams into the catalog. The two are separate: sign-in is application configuration, and organization sync is a Marketplace module with its own configuration.

The 3.x backend registers the github sign-in provider, with the userIdMatchingUserEntityAnnotation resolver as its default. Sign-in succeeds only when the catalog already holds a matching User entity, so set up organization sync before you test sign-in.

Prerequisites​

You need:

Configure GitHub sign-in​

Add this block to a custom configuration fragment on the local stack (see Add configuration to the local stack), or to an extraAppConfig fragment in the chart values.yaml. Replace the placeholder values with your OAuth App credentials. The production entry must match auth.environment.

auth:
  environment: production
  providers:
    github:
      production:
        clientId: ${AUTH_GITHUB_CLIENT_ID}
        clientSecret: ${AUTH_GITHUB_CLIENT_SECRET}
        signIn:
          resolvers:
            - resolver: userIdMatchingUserEntityAnnotation
signInPage: github

What the keys do:

  • clientId and clientSecret identify your GitHub OAuth App. See the Backstage GitHub provider documentation.
  • signIn.resolvers maps the GitHub identity to a catalog User entity. The default resolver matches the immutable GitHub user ID against the github.com/user-id annotation on the User entity, which the organization sync module sets. See Sign-in identities and resolvers.
  • signInPage: github makes GitHub the sign-in method.

Pass the secrets as environment variables rather than writing them into the file. On the local stack, set them on the devportal service in a Compose override:

services:
  devportal:
    environment:
      AUTH_GITHUB_CLIENT_ID: your-github-oauth-app-client-id
      AUTH_GITHUB_CLIENT_SECRET: your-github-oauth-app-client-secret

On Kubernetes, store them in the runtime Secret and reference them with ${...} placeholders, following the veecode-runtime-secrets pattern in Install DevPortal on Kubernetes. Restart the portal so it loads the new configuration. The portal can take up to two minutes before /healthcheck returns 200; test sign-in after that.

Import users and teams​

The github-org module imports GitHub users and teams as User and Group entities on a schedule. Install it from the Marketplace Extensions page, or add this entry to an operator plugin file (see Configure dynamic plugins for the local stack):

plugins:
  - package: oci://quay.io/veecode/backstage-plugin-catalog-backend-module-github-org@sha256:0e61273f85ba64ea304d262f84f884a915a9f783946dea96928adb67935345d8
    disabled: false
    pluginConfig:
      catalog:
        providers:
          githubOrg:
            id: production
            githubUrl: ${GITHUB_URL}
            orgs:
              - ${GITHUB_ORG}
            schedule:
              frequency:
                minutes: 60
              initialDelay:
                seconds: 15
              timeout:
                minutes: 15

Set GITHUB_URL to https://github.com (or your GitHub Enterprise URL) and GITHUB_ORG to your organization name. The module needs a token with organization read access; configure repository access as described in GitHub backend integrations.

After the first sync runs, open the catalog and check that User entities from your organization are present. Then sign in with a GitHub account from that organization.

Sign-in resolvers​

The backend default is userIdMatchingUserEntityAnnotation: it matches the GitHub user ID with the User entity carrying the same github.com/user-id annotation. Prefer this resolver because GitHub usernames can change while user IDs cannot, as noted in the Backstage GitHub provider documentation.

Other resolvers from that page, such as emailMatchingUserEntityProfileEmail, work when your User entities carry the matching fields. List resolvers in order; each one is tried until one finds a match.

Troubleshooting​

  • Sign-in fails with an identity resolution error: the User entity is missing from the catalog. Wait for the next organization sync and confirm the user appears in the catalog before signing in again.
  • The GitHub button does not appear: check that auth.environment matches the provider entry name (production in the example) and that the portal restarted with the fragment loaded.
  • Redirect mismatch after GitHub approval: the callback URL in the OAuth App must exactly match http(s)://<portal-host>/api/auth/github/handler/frame.
